em-trak X100 NMEA 2000 Bluetooth Wi-Fi VHF/DSC Radio with Class B AIS and Antenna Splitter (431-0001)

The em-trak X100 DSC/VHF Radio with Class B AIS (part number 431-0001) is a comprehensive marine communication system that combines a certified Class D VHF/DSC radio with a high-powered 5W Class B SOTDMA AIS transceiver in a single, rugged unit. It is designed to enhance navigation safety and convenience through a range of integrated functionalities, including wireless control via mobile devices.

The X100 defines a new horizon of functionality, performance, and convenience in marine radio communications and navigation safety. Integrated DSC/VHF radio and high-powered AIS Class B combine with a range of innovative functionalities that make your boating safer and more convenient.

Engineered & Built for Boating Life

• Ruggedized, water and weather-proof
• CLEAR-WAVE digital audio processing
• The full-color direct-sunlight visible display
• WiFi & Bluetooth
• NMEA2000 & 0183
• Integrated GPS (external antenna optional)
• Integrated zero-loss VHF antenna splitter – only one antenna is required for both AIS and VHF
• Ergonomic intuitive controls and UI
• Flush, desktop, ceiling mounting options

Outstanding Functionalities that Enhance Your Boating

• CONNECT-X - Transform your smartphone or smartwatch into a full-feature wireless command mic. You can use it to make and receive calls, monitor VHF/DSC, AIS traffic, and nav alerts anywhere on your boat.
• VHF/DSC – X100 is a certified Class DVHF/DSC marine radio with a full feature globally certified Class D VHF/ DSC radio.
• Chat to anyone on the boat using the Connect-X private intercom functionality.
• Enable the MOB function and be alerted to any connected device that leaves the boat.
• High-powered AIS that receives and transmits. Integrated navigation alerts allow you to go silent and stop transmitting when you want.
• Single system-wide phonebook for Vessel DSC, AIS & On-board Intercom for consistent communication by whatever means vessel-wide.
• Wi-Fi Access Point mode is for standalone installation, and Station mode is for integration within existing vessel Wi-Fi infrastructure for a scalable solution that will meet the needs of solo mariners on small boats to medium to large motor yachts and sailing vessels.
• Streaming of all received AIS data to navigation apps on tablets and phones over Wi-Fi to easily integrate 3rd party navigation apps into your system.
• Autoset DSC “Nature of Distress” when in a MOB situation for the quicker triggering of DSC distress following a MOB situation.
• Initiation of DSC calling from Phonebook, AIS List/Plot, or via direct entry of MMSI to make using DSC much more convenient, quicker, and feature-rich without having to enter MMSI numbers directly.

Advanced Features for Enhanced Safety & Communication:

• VHF/DSC
• Wireless Command-Mic
• AIS
• Private Intercom
• MOB
• One Touch Calling

CONNECT-X Turns Your Phone into a Radio Command Mic

With the powerful yet free CONNECT-X app, you can wirelessly connect up to 10 mobile devices and turn them into full-function mobile radio command mics allowing you to manage communication, navigation, and emergency functions from anywhere onboard.

Free CONNECT-X App

• Respond immediately to emergencies with instant MOB alerts and recovery locations, as well as CPA, anchor drift, and inbound DSC messages.
• Maintain full control over VHF communications from any location on the vessel.
• Privately intercom crew and PA throughout the vessel and loudhail other vessels nearby.

Specifications:

• Dimensions (W x H x D): 9.8" x 3.3" x 6.4" (249 x 84 x 162 mm)
• Weight: 1.5 lbs (700 g)
• RF Frequency range:
  • TX: 156.025-161.425 MHz
  • RX: 156.300-161.925 MHz
• DSC: 156.525 MHz
• AIS 1, 2: 161.975, 162.025 MHz
• Usable Channels: INT, USA, CAN, ATIS
• Power Supply: 9.6 - 31.2V DC
• Operating Temperature Range: -13° to 154° F (-25° to 68° C)
• Antenna Impedance: 50 Ohms
• Transmitter Output Power: VHF: 25W, 1W AIS: 5W
• Audio Output Power - Internal Speaker: 5W producing 81 dB @ 1 m
• External Speaker/Loudhailer: 15W
• NMEA 0183/NMEA 2000: Ed 3.101
• Wireless LAN Standards: IEEE802.11 b/g/n
• Authentication and Encryption: WEP (64/128 bit), WPAPSK (TKIP), WPA2-PSK (AES)
• Bluetooth: 4.2 classic and low energy (BLE)
• AIS Class B SOTDMA Certification: I EC 62287-2:2017
• DSC/VHF Certification: EN 301025 v2.2.1 and IEC 62238
• NMEA Certification: IEC 61162-1 and IEC 61162-3
• Environmental Certification: IEC 60945 "Exposed" + IEC 60529 IP66

In the box:
