Diamond Audio MICRO5V2 650W RMS 5-Channel Class D Car Amplifier

Diamond Audio MICRO5V2 Micro Series 5-Channel Class D Amplifier
Power your entire audio system with the Diamond Audio MICRO5V2, a 5-channel Class D amplifier from the Micro Series, delivering 950W RMS for car and motorcycle applications. With a compact design, DirectFET MOSFET technology, and Bluetooth-ready connectivity, this amplifier ensures premium sound quality and versatility, perfect for full-range audio setups.

Key Features

• Full-Range Power: Delivers 80W x 4 + 200W x 1 at 4 ohms for comprehensive audio performance.
• Ultra-Compact Build: Fits in tight spaces for flexible installation options.
• Advanced Technology: DirectFET MOSFET and balanced differential inputs for efficiency.
• Customizable Audio: Variable 12dB/octave crossovers for precise sound tuning.
• Bluetooth Compatibility: BTR port enables seamless integration with Bluetooth receivers.

Specifications

• Power Output: 80W x 4 + 200W x 1 at 4 ohms; 150W x 4 + 350W x 1 at 2 ohms; 300W x 2 + 200W x 1 at 4 ohms Bridged
• Frequency Response: 20Hz-30kHz
• Dimensions: 10.65" L x 4.0" W x 1.46" H (270.5 x 103 x 37.2 mm)
• Crossover: High-Pass: Flat/Fixed 70Hz; Low-Pass: 40Hz-400Hz, 12dB/octave
• Sensitivity: 200mV-10V
• Fuse Rating: 60A

Package Contents

• 1 Diamond Audio MICRO5V2 Amplifier
• Wired Remote Level Control with Cable
• Power and Signal Input Connectors
• Mounting Brackets and Hardware
• Installation Manual

Why Choose the Diamond Audio MICRO5V2?

The MICRO5V2 delivers unmatched power and versatility with Bluetooth-ready connectivity, making it the perfect choice for audiophiles seeking a complete, high-performance audio solution.
